Factory making for Ce Certification Mechanical Diaphragm Chemical Dosing Pump Auotomatic Diaphragm Dosing Pump supply to Paraguay Factory

Share to:
    Payment Type: L/C,T/T
    Incoterm: FOB
    Min. Order: 10 Bag/Bags
    Delivery Time: 10 Days
  • Product Detail
  • Product Tags
  • Buyer Reviews

Responsible excellent and fantastic credit rating standing are our principles, which will help us at a top-ranking position. Adhering towards the tenet of "quality initial, buyer supreme" for Diaphragm Pump with Automatic Control,Adjustable Conntrol Dosing Pump,Auto Model Diaphragm Metering Pump. We're self-assured that there will be a promising foreseeable future and we hope we can have lasting cooperation with shoppers from all around the entire world.

Factory making for Ce Certification Mechanical Diaphragm Chemical Dosing Pump Auotomatic Diaphragm Dosing Pump supply to Paraguay Factory

Product Description

We are factory, and our factory has the independent research and development capacity. Based on different requirement come from various customers, we intends to recommend most suitable type for them, we believe that our product is stable, reliable with perfect performance.

The JXM-A series of dosing pumps offer the high performance with the capacity up to 1200L/H and with outstanding values for pressure applications up to 12 Bar. This series dosing pump is designed for durability and cost effectiveness, which is welcome to be unsed in lots of lines, such as the water treatment, chemical, power, food and beverage, paper, textile etc.

l/h

  (Mpa)



(mm)

(mm)

(KW)

(KG)

JXM-A 2.25/1.2

2.25

1.2

36

1.2

DN8

0.37KW

18

JXM-A 4.5/1.2

4.5



JXM-A 9/1.2

9

144

JXM-A 22/1.2

22

72

4

DN15

JXM-A 44/1.2

44

144

JXM-A 85/1.0

85

1

72

6

JXM-A 120/0.7

120

0.7

72

8

JXM-A 170/0.7

170

144

6

JXM-A 240/0.7

240

144

8

DN25

JXM-A 315/0.5

315

0.5

144

8

0.55KW

JXM-A 400/0.5

400

144

10

JXM-A 500/0.5

500

180

Products Show
Diaphragm Pump with Automatic Control

Technical Specifications

* Flow rates up to 500L/H, pressure up to 12Bar

* Adjustment of flowrate from 0% - 100% while running or stopped

* Accuracy +/- 2% of 100% rated flow

* Mechanically actuated PTFE diaphragm

* Maximum temperature of pumped fluid: +10℃ - 40℃

* Maximum suction up to 2M

Features & Benefits

* Mechanical actuated diagragm design, easy operation and with the convenience maintanence

* Changeable eccentric drive, no leakage with security delivery

* Rugged construction designed to withstand tough environments

* Oil bath lubrication for all of drive components

* Various pump head material (PVC, PVDF, SS304, SS316 etc.) to meet different solution needs

* Available with the manual control and digital control model

Control

* Stroke actuator with 4-20mA signal
* Digital controller with 4-20mA signal

Others

* The Pump can be used to deliver the solution which is high-viscosity, corrosive and dangerous

* Diaphragm rupture detection system (Double diaphragm) is optional.

Diaphragm Pump with Automatic ControlDiaphragm Pump with Automatic Control

Digital Controller: Technical Parameter

* Ambient Temp: 0 --- 50℃
* Input Control Signal (standard): 4 ---20 mA
* Power Supply (standard): 220V +/- 10%, 1 phase, 50Hz
* Highest loaded power: 0.55KW
* Remote ON/OFF: Dry Contact switch
* Alarm - Output: 220V switch
* Signal Input:
     A: 4 --- 20mA simulation signal
     B: Hall signal: Use Non-touching Hall signal to change pulse into flow signal
                                   Wave: Rectangle
                                    Extent: Over 3.5V
     Output Voltage: +/- 12VDC
