Manufacturer of for Impulse Control Metering Pump Wastwater Diaphragm Dosing Pump export to Cayman Islands Factory

Share to:
    Payment Type: L/C,T/T
    Incoterm: FOB
    Min. Order: 10 Bag/Bags
    Delivery Time: 5 Days
  • Product Detail
  • Product Tags
  • Buyer Reviews

priority in company and will do our greatest to provide our customers with high-quality goods and fantastic provider. for Watertreatment Diaphragm Pump,Injection Chemical Dosing Pump,Dose Chemical Metering Pump. All merchandise are manufactured with advanced equipment and strict QC procedures in buy to be certain superior quality. Welcome customers new and aged to get in touch with us for enterprise cooperation.

Manufacturer of for Impulse Control Metering Pump Wastwater Diaphragm Dosing Pump export to Cayman Islands Factory

Product Description

The JXM-A series of dosing pumps offer the high performance with the capacity up to 1200L/H and with outstanding values for pressure applications up to 12 Bar. This series dosing pump is designed for durability and cost effectiveness, which is welcome to be unsed in lots of lines, such as the water treatment, chemical, power, food and beverage, paper, textile etc.


l/h

  (Mpa)



(mm)

(mm)

(KW)

(KG)

JXM-A 2.25/1.2

2.25

1.2

36

1.2

DN8

0.37KW

18

JXM-A 4.5/1.2

4.5



JXM-A 9/1.2

9

144

JXM-A 22/1.2

22

72

4

DN15

JXM-A 44/1.2

44

144

JXM-A 85/1.0

85

1

72

6

JXM-A 120/0.7

120

0.7

72

8

JXM-A 170/0.7

170

144

6

JXM-A 240/0.7

240

144

8

DN25

JXM-A 315/0.5

315

0.5

144

8

0.55KW

JXM-A 400/0.5

400

144

10

JXM-A 500/0.5

500

180

Mechanical Diaphragm Dosing Pump
Product Show
Mechanical Diaphragm Dosing PumpMechanical Diaphragm Dosing Pump
Mechanical Diaphragm Dosing Pump

Technical Specifications

* Flow rates up to 500L/H, pressure up to 12Bar
* Adjustment of flowrate from 0% - 100% while running or stopped
* Accuracy +/- 2% of 100% rated flow
* Mechanically actuated PTFE diaphragm
* Maximum temperature of pumped fluid: +10℃ - 40℃
* Maximum suction up to 2M

Features & Benefits

* Mechanical actuated diagragm design, easy operation and with the convenience maintanence
* Changeable eccentric drive, no leakage with security delivery
* Rugged construction designed to withstand tough environments
* Oil bath lubrication for all of drive components
* Various pump head material (PVC, PVDF, SS304, SS316 etc.) to meet different solution needs
* Available with the manual control and digital control model

Control

* Manual stroke adjustment
* Stroke actuator with 4-20mA signal
* Digital controller with 4-20mA signal

Our Employees
Our Company
Our Certifications
FAQ

Q: Are you trading company or manufacturer ?

A: We are factory, and our factory has the independent research and development capacity

Q: How long is your delivery time?

A:Generally it is 3 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer sample but it must be paid

Q: What is your terms of payment ?

A:TT, LC. etc.....

"Sticking on the belief of ""Creating goods of top of the range and creating buddies with persons from everywhere in the world"", we normally put the fascination of shoppers in the first place for Wastwater Diaphragm Dosing Pump. The product will supply to all over the world, such as: Northern Mariana Islands,Poland,Pitcairn. We focus on providing service for our clients as a key element in strengthening our long-term relationships. Our continual availability of high grade items in combination with our excellent pre-sale and after-sales service ensures strong competitiveness in an increasingly globalized market. We are willing to cooperate with business friends from at home and abroad and create a great future together.
