Online Manufacturer for for Large Automatic Control Mechanical Diaphragm Dosing Pump Automatic Chemical Diaphragm Metering Pump export to Nepal Factory

Product Description

The JXM-A series of dosing pumps offer the high performance with the capacity up to 1200L/H and with outstanding values for pressure applications up to 12 Bar. This series dosing pump is designed for durability and cost effectiveness, which is welcome to be unsed in lots of lines, such as the water treatment, chemical, power, food and beverage, paper, textile etc.

l/h

  (Mpa)



(mm)

(mm)

(KW)

(KG)

JXM-A 2.25/1.2

2.25

1.2

36

1.2

DN8

0.37KW

18

JXM-A 4.5/1.2

4.5



JXM-A 9/1.2

9

144

JXM-A 22/1.2

22

72

4

DN15

JXM-A 44/1.2

44

144

JXM-A 85/1.0

85

1

72

6

JXM-A 120/0.7

120

0.7

72

8

JXM-A 170/0.7

170

144

6

JXM-A 240/0.7

240

144

8

DN25

JXM-A 315/0.5

315

0.5

144

8

0.55KW

JXM-A 400/0.5

400

144

10

JXM-A 500/0.5

500

180

Automatic controllable metering pump
Products Show
Automatic controllable metering pump

Technical Specifications

* Flow rates up to 500L/H, pressure up to 12Bar

* Adjustment of flowrate from 0% - 100% while running or stopped

* Accuracy +/- 2% of 100% rated flow

* Mechanically actuated PTFE diaphragm

* Maximum temperature of pumped fluid: +10℃ - 40℃

* Maximum suction up to 2M

Features & Benefits

* Mechanical actuated diagragm design, easy operation and with the convenience maintanence

* Changeable eccentric drive, no leakage with security delivery

* Rugged construction designed to withstand tough environments

* Oil bath lubrication for all of drive components

* Various pump head material (PVC, PVDF, SS304, SS316 etc.) to meet different solution needs

* Available with the manual control and digital control model

Control

* Stroke actuator with 4-20mA signal
* Digital controller with 4-20mA signal

Others

* The Pump can be used to deliver the solution which is high-viscosity, corrosive and dangerous

* Diaphragm rupture detection system (Double diaphragm) is optional.

Automatic controllable metering pump
Automatic controllable metering pump

Digital Controller: Technical Parameter

* Ambient Temp: 0 --- 50℃
* Input Control Signal (standard): 4 ---20 mA
* Power Supply (standard): 220V +/- 10%, 1 phase, 50Hz
* Highest loaded power: 0.55KW
* Remote ON/OFF: Dry Contact switch
* Alarm - Output: 220V switch
* Signal Input:
     A: 4 --- 20mA simulation signal
     B: Hall signal: Use Non-touching Hall signal to change pulse into flow signal
                                   Wave: Rectangle
                                    Extent: Over 3.5V
     Output Voltage: +/- 12VDC
